Sennheiser EW-DP ENG SET Q1-6

Start 360°

Fully Digital Portable UHF Wireless System

For video applications with ME 2 condenser lavalier microphone and EW-DP SKP plug-on transmitter
Frequency range Q1-6: 470 - 526 MHz
Bluetooth for synchronisation and control
Intelligent notifications for error management
Battery life: transmitter up to 12 hours/receiver up to 7 hours
Digital plug-on transmitter with +48V phantom power
Dynamic range: 134 dB
System latency: 1.9 ms
Transmitter power: 10 mW
Up to 56 MHz switching bandwidth
Receiver stackable and magnetically mountable
Receiver charging possible via USB-C port
Smart Assist app for monitoring and control
Receiver dimensions (W x H x D): 86 x 28 x 67 mm
Pocket transmitter dimensions (W x H x D): 63 x 80 x 20 mm
Receiver weight: 140 g
Weight of pocket transmitter: 120 g
Includes ME 2 clip-on microphone (omnidirectional), EW-DP SKP digital plug-on transmitter, mounting kit, BA 70 Li-ion battery, two AA batteries, 3.5 mm TRS mini jack to 3.5 mm TRS mini jack (lockable) cable, 3.5 mm TRS mini jack (lockable) to XLR male cable and USB-C charging cable

30-Day Money-Back Guarantee

3-Year Thomann Warranty

Available since October 2023
Item number 564166
Sales Unit 1 piece(s)
Capsule Type Condenser
Microphone Colour Black
Receiver Type mobile
Frequency 470 MHz – 526 MHz
Transmission system Digital
Channels Lapel Microphone 1
Dante No
Frequency Band UHF
Transmitting System Digital
Wireless Channels 1
Diversity Yes
Pattern omnidirectional
Mic Model 141903
Handheld Transmitter 0
Removeable Antenna Yes
Pocket Transmitter 1
Microphone Plug Transmitter 1
Transmitter powerd with 2x AA
Receiver Width in mm 86 mm
Power Transmitter Li-ion Battery
Multi Channel No
Receiver Height in mm 28 mm
Receiver Depth in mm 67 mm
Microphone Type Lapel
Receiver Weight in kg 0,14 kg
Transmitter Input 3,5mm TRS
Hot Shoe Adaptor No
Transmitting Power in mW 10 mW
Switching Bandwidth in MHz 56 MHz
Frequency Display Yes
Power Receiver 2x AA
Frequency Scan Yes
Removable Antenna Yes
Battery Status Monitor Yes
Output 3,5mm TRS
Charging System Optional
Rackkit No

Show variations of this product

Sennheiser EW-DP ENG SET Q1-6

Sennheiser EW-DP ENG SET Q1-6 Fully Digital Portable UHF Wireless System * For video applications with ME 2 condenser la...

$845

to the product

Sennheiser EW-DP ENG SET R1-6

Sennheiser EW-DP ENG SET R1-6 Fully Digital Portable UHF Wireless System * For video applications with ME 2 condenser la...

$858

to the product

Sennheiser EW-DP ENG SET U1/5

Sennheiser EW-DP ENG SET U1/5 Fully Digital Portable UHF Wireless System * For video applications with ME 2 condenser la...

$849

to the product

$845

The shipping costs are calculated on the checkout page.

Sales Rank

in Wireless Microphones with Lapell Microphones

Information on the supported frequency ranges

Here you can see which frequencies are supported by this wireless system and the countries in which these frequencies are allowed in the future for wireless applications.

All information is without guarantee
